832 Serie Soft-Close 105° half overlay hinge wood screws fixing

Product code: PEN-RS105-MVB

The full range of 832 serie hinges offers a wide range of products to set different types of doors in motion. Whether for large door openings such as wardrobes or pantries, for regular door openings, or for corner cabinets, the 832 serie hinge can be used in all regular furniture applications for house.

• Application: Standard door • Half-overlay • Opening angle: 105° • With damper • With closing spring • Fixing type: Wood screws • Drilling pattern: 45 / 9.5 mm • Cup drilling diameter: 35 mm • Drilling depth: 12 mm • Cup distance: 3 to 7 mm • Maximum door thickness: 22 mm • Vertical adjustment (On mounting plate): +/- 2 mm • Lateral adjustment: + 1 / - 6 mm • Depth adjustment: +2 / -1 mm • Finish: Nickel-plated

Having the same design and the same mounting plates, hinge versions with or without dampers are available for all models and can be mounted on the same door. They guarantee an excellent cost / quality of movement.
